E550028 ECHU Cable UL3641 180°C 3300V Silicone Rubber Single-Core Cable

Name: E550028 ECHU Cable UL3641 180°C 3300V Silicone Rubber Single-Core Cable
Brand: ECHU Special Wire & Cable (Kunshan) Co., Ltd.
SKU: UL3641
Price: 2.30 USD
Availability: InStock

Brand Name:	ECHU
Model Number:	UL3641
MOQ:	100meter
Price:	USD0.302 to USD6.285/m
Payment Terms:	T/T, L/C
Supply Ability:	10000km per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

Black/red/....

Voltage:

3300V

Temperature:

-60-+180℃

Condutor:

Bare Copper Or Tinned Copper

Packaging Details:

in roll or splint reel

Product Description

UL3641 Single-Conductor Silicone Rubber AWM Cable

UL3641 is a high-voltage & high-temperature silicone wire complying with UL758 Appliance Wiring Material standard.

Construction Conductor: Solid or Class 5 flexible stranded bare / tinned copper (16AWG ~ 600kcmil); Insulation: Extruded silicone rubber (SR).
Electrical & Thermal Ratings Rated Voltage: 3300V AC Rated Temperature: 150°C / 180°C (dry locations) Operating temperature range: -60°C ~ +180°C
Flame Performance Self-extinguishing, meets UL FT2 horizontal flame test.
Key Features Excellent flexibility, outstanding heat resistance, low-temperature resistance, ozone resistance, UV resistance and chemical resistance. High dielectric strength for high voltage circuits. Uniform insulation thickness for easy stripping; halogen-free and RoHS compliant. Fiberglass braid covering is optional.
Typical Applications Internal wiring for high-temperature electrical equipment, motors, transformers, heating devices, ovens, inverters, new energy equipment and industrial machinery.

UL3641 180°C 3300V Silicone Rubber Single-Core Cable
Item	UL3641 180°C 3300V Silicone Rubber Single-Core Cable
Conductor	Flexible Stranded Copper Conductor
Insulation	Silicone Rubber
Outer Sheath	Not Applicable
Nominal Voltage	3300V
Test voltage	7000V
Temperature Range	-60°C/+180°C
Color	Optional
Application	This cable is mainly used for internal wiring in high temperature areas such as household appliances. lighting, heaters, motors, dryers, ovens, etc.
