E550028 ECHU UL Rubber Cable Single conductor with extruded EPDM insulaiton UL3478 26AWG -4/0AWG 600V 125℃ with UL certificate

Name: E550028 ECHU UL Rubber Cable Single conductor with extruded EPDM insulaiton UL3478 26AWG -4/0AWG 600V 125℃ with UL certificate
Brand: ECHU Special Wire & Cable (Kunshan) Co., Ltd.
SKU: UL3478
Price: 0.66 USD
Availability: InStock

Brand Name:	ECHU
Model Number:	UL3478
MOQ:	300Meters
Price:	USD0.655-USD2.288/M
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	10000km/week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Related Temperature:

125℃

Rated Voltage:

600V

Insulation:

Extruded EPDM

Color:

Red/white/black/blue/yellow....

Packaging Details:

100M/roll

Product Description

EPDM insulation Cable UL CABLE UL3478

UL Approval

Rating: 125 deg C, 600 Vac, Horizontal flame.

Conductor: 26 AWG - 4/0AWG, solid or stranded

Standard: Appliance Wiring Material UL 758

Application:
Internal Wiring of Lighting Fixtures, Appliances or Electronic Equipment, where exposed to temperatures not exceeding 125 deg C.

Type	Size	O.D.(mm)	Weight(KG/KM)
UL3478	26AWG	2.2	8
UL3478	25AWG	2.3	8
UL3478	24AWG	2.4	9
UL3478	23AWG	2.4	10
UL3478	22AWG	2.5	11
UL3478	21AWG	2.6	12
UL3478	20AWG	2.7	13
UL3478	19AWG	2.8	15
UL3478	18AWG	2.9	17
UL3478	17AWG	3.1	19
UL3478	16AWG	3.2	23
UL3478	15AWG	3.4	27
UL3478	14AWG	3.6	32
UL3478	13AWG	3.9	38
UL3478	12AWG	4.1	45
UL3478	11AWG	4.6	56
UL3478	10AWG	4.9	68
UL3478	9AWG	5.3	84
UL3478	8AWG	6.5	113
UL3478	7AWG	7.7	148
UL3478	6AWG	8.8	186
UL3478	5AWG	9.5	225
UL3478	4AWG	10.2	272
UL3478	3AWG	11.2	332
UL3478	2AWG	12.1	405
UL3478	1AWG	14.1	526
UL3478	1/0AWG	15.2	642
UL3478	2/0AWG	16.6	789
UL3478	3/0AWG	18.1	973
UL3478	4/0AWG	19.8	1203
