E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color

Certification
Good quality Solar PV Cable for sales
Good quality Solar PV Cable for sales
I'm Online Chat Now

E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color

China E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color supplier
E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color supplier E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color supplier E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color supplier E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color supplier E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color supplier

Large Image :  E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color

Product Details:

Place of Origin: China
Brand Name: ECHU
Certification: UL
Model Number: UL1283

Payment & Shipping Terms:

Minimum Order Quantity: 100m
Price: USD0.312-USD1.966/M
Packaging Details: in roll or splint reel
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10000km per week
Detailed Product Description
Conductor: Copper Or Tinned Copper Voltage: 600V,
Color: Different Colors Temperature: 105 ℃
Insulation: Double Insulation

UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color



Production description:

UL CERT.:E312831



Single Conductor Single Core Flexible Wire UL1283 PVC Insulated 8 AWG,7AWG,6AWG,5AWG,4AWG,3AWG,2AWG

Construction
Conductor :bare copper or tinned copper conductor
Insulation: PVC
Standards
International: UL758 , UL1581
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature:105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
Voltage withstand test:AC 2.5kV/1min



E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color



E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color



E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color

E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color

E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 6AWG 105℃ Electrical Wire in Black color



TYPE
Spec. AWG
Bare Copper

Tinned Copper

Insulation Thickness mm
Weight KG/KM


Conductor No.
Conductor Dia.
Conductor No.
Conductor Dia.


UL1283
8
118
0.3
118
0.30
1.52
119.5
UL1283
7
147
0.3
147
0.30
1.52
141.8
UL1283
6
189
0.3
189
0.30
1.52
173.4
UL1283
5
238
0.3
238
0.30
1.52
209.7
UL1283
4
299
0.3
299
0.30
1.52
254.3
UL1283
3
378
0.3
378
0.30
1.52
311.2
UL1283
2
475
0.3
475
0.30
1.52
380.2
