ROHS PVC Electrical Single core Cable UL1617 105℃ 600V with UL Certificate in Red Color
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Color: | Red/black/white/yellow/green |
|---|
UL CERT. No.:E312831
UL1617 Hook up Wire Description:
Related temperature: 105℃
Related voltage: 600V
Reference standards: UL Subject 758 & UL 1581/CSA C22.2 NO.210.05
Tinned or bare, stranded or solid copper conductor 5AWG-26AWG
Insulation: Color-coded PVC insulation
Sheath: Rohs PVC
Uniform insulation thickness to ensure easy stripping and cutting
Passes UL VW-1 flame test and CSA FT1 flame test
Application:
For internal wiring of electronic and electric equipment. can be substituted by UL10938
the electric normal cable is 5AWG/6AWG/7AWG/8AWG/9AWG/ 10AWG/11AWG/12AWG/13AWG/14AWG/16AWG/17AWG/18AWG/20AWG/22AWG/24AWG/26AWG 600 V..
|
TYPE
|
Sec. AWG
|
Copper Conductor/Tinned copper
|
|
|
|
|
Con. No.
|
Cond.Dia.
|
|
UL1617
|
26
|
7
|
0.16
|
|
UL1617
|
24
|
11
|
0.16
|
|
UL1617
|
22
|
17
|
0.16
|
|
UL1617
|
20
|
26
|
0.16
|
|
UL1617
|
18
|
41
|
0.16
|
|
UL1617
|
17
|
51
|
0.16
|
|
UL1617
|
16
|
26
|
0.254
|
|
UL1617
|
15
|
33
|
0.254
|
|
UL1617
|
14
|
41
|
0.254
|
|
UL1617
|
13
|
52
|
0.254
|
|
UL1617
|
12
|
65
|
0.254
|
|
UL1617
|
11
|
82
|
0.254
|
|
UL1617
|
10
|
104
|
0.254
|
|
UL1617
|
9
|
94
|
0.30
|
|
UL1617
|
8
|
118
|
0.30
|
|
UL1617
|
7
|
147
|
0.30
|
|
UL1617
|
6
|
189
|
0.30
|
|
UL1617
|
5
|
238
|
0.30
|
