ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color

China ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier
ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color supplier

Large Image :  ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color

Product Details:

Place of Origin: China
Brand Name: ECHU
Certification: UL
Model Number: UL2464

Payment & Shipping Terms:

Minimum Order Quantity: 300meters
Price: USD0.112-USD0.558/M
Packaging Details: Splint reel or box
Delivery Time: 7 to 10days
Payment Terms: T/T, Western Union
Supply Ability: 10000km/week
Detailed Product Description
Color: Black/grey/white..

Heat resistance,
Good insulation property,
UL certificate

UL2464 Wire and Cable

Applications:

As measuring, monitoring and control cable, it is suitable for the places of machine tool manufacturing, complete equipment installation engineering, power station, refrigeratory equipment, OA equipment, data processing system and heating and air-condition system.

Properties:

Heat resistance, good insulation property, excellent chemical performance, extruding sheath

Standards: UL 758

Structure:

Conductor: Fine strands of tinned copper wire, exellent corrosion resistance.

Insulation: Special PVC

Colour: Acc. To UL 758

Sheath: 80 heat-resistant flame-resistant PVC, pass VW-1 flame testing

Colour: Black (RAL9005) green (RAL6018)

Orange(RAL2003) purple(RAL4001)

Or refer to customers requirement.

Technical data:

Rated voltage: 300V

Test voltage: 2000V


Temperature range

Fixed installation: -40C to +80C

Flexing Installation: -10C to +80C



The minimum bending radius:

Fixed installation: 4Xouter diameter

Flexing installation: 15Xouter diameter

ROHS PVC Electrical Shealth Multi-conductor cable UL2464 80℃ 300V with UL Certificate in Green Color

Type Size Conductor Conductor OD:φ Weight  KG/KM OD down limited mm OD up limited mm
UL2464 26AWG*2C 7 0.16 24.5 4.0 4.4
UL2464 26AWG*3C 7 0.16 28 4.2 4.6
UL2464 26AWG*4C 7 0.16 32.9 4.5 4.9
UL2464 26AWG*5C 7 0.16 38.1 4.9 5.3
UL2464 26AWG*6C 7 0.16 43.6 5.3 5.7
UL2464 26AWG*7C 7 0.16 46.6 5.3 5.7
UL2464 26AWG*8C 7 0.16 52.1 5.6 6
UL2464 26AWG*9C 7 0.16 59 6.2 6.6
UL2464 26AWG*10C 7 0.16 65.7 6.5 6.9
UL2464 26AWG*11C 7 0.16 70.7 6.7 7.1
UL2464 26AWG*12C 7 0.16 72.8 6.7 7.1
UL2464 26AWG*13C 7 0.16 75.7 7.1 7.5
UL2464 26AWG*14C 7 0.16 78.7 7.1 7.5
UL2464 26AWG*15C 7 0.16 84.5 7.4 7.8
UL2464 26AWG*16C 7 0.16 87.6 7.4 7.8
UL2464 26AWG*17C 7 0.16 93.6 7.8 8.2
UL2464 26AWG*18C 7 0.16 96.6 7.8 8.2
UL2464 26AWG*19C 7 0.16 99.6 7.8 8.2
UL2464 26AWG*20C 7 0.16 104.2 8.0 8.4
UL2464 26AWG*21C 7 0.16 108.7 8.2 8.6
UL2464 26AWG*22C 7 0.16 116 8.7 9.1
UL2464 26AWG*23C 7 0.16 122.3 9.1 9.5
UL2464 26AWG*24C 7 0.16 125.3 9.1 9.5
UL2464 26AWG*25C 7 0.16 130.1 9.3 9.7
UL2464 26AWG*26C 7 0.16 133.1 9.3 9.7
UL2464 26AWG*27C 7 0.16 136.1 9.3 9.7
UL2464 26AWG*28C 7 0.16 142.1 9.6 10.0
UL2464 26AWG*29C 7 0.16 145.1 9.6 10.0
UL2464 26AWG*30C 7 0.16 148.2 9.6 10.0
UL2464 26AWG*31C 7 0.16 154.5 10.0 10.6
UL2464 26AWG*32C 7 0.16 157.5 10.0 10.6
UL2464 26AWG*33C 7 0.16 160.6 10.0 10.6
UL2464 26AWG*34C 7 0.16 167.2 10.4 11
UL2464 26AWG*35C 7 0.16 170.2 10.4 11
UL2464 26AWG*36C 7 0.16 173.2 10.4 11
UL2464 26AWG*37C 7 0.16 171.3 10.2 10.8

UL2464 24AWG*2C 11 0.16 27.2 4.1 4.5
UL2464 24AWG*3C 11 0.16 31.7 4.4 4.8
UL2464 24AWG*4C 11 0.16 37.8 4.7 5.1
UL2464 24AWG*5C 11 0.16 44.3 5.1 5.5
UL2464 24AWG*6C 11 0.16 51.1 5.6 6
UL2464 24AWG*7C 11 0.16 55.2 5.6 6
UL2464 24AWG*8C 11 0.16 62.1 6 6.4
UL2464 24AWG*9C 11 0.16 70.6 6.6 7
UL2464 24AWG*10C 11 0.16 79 7 7.4
UL2464 24AWG*11C 11 0.16 85.4 7.3 7.7
UL2464 24AWG*12C 11 0.16 88.3 7.3 7.7
UL2464 24AWG*13C 11 0.16 91.7 7.6 8
UL2464 24AWG*14C 11 0.16 95.8 7.6 8
UL2464 24AWG*15C 11 0.16 103 8 8.4
UL2464 24AWG*16C 11 0.16 107.1 8 8.4
UL2464 24AWG*17C 11 0.16 114.6 8.5 8.9
UL2464 24AWG*18C 11 0.16 118.7 8.5 8.9
UL2464 24AWG*19C 11 0.16 122.8 8.5 8.9
UL2464 24AWG*20C 11 0.16 128.7 8.7 9.1
UL2464 24AWG*21C 11 0.16 134.5 8.9 9.3
UL2464 24AWG*22C 11 0.16 143.5 9.5 9.9
UL2464 24AWG*23C 11 0.16 151.3 9.9 10.5
UL2464 24AWG*24C 11 0.16 155.4 9.9 10.5
UL2464 24AWG*25C 11 0.16 161.5 10.2 10.8
UL2464 24AWG*26C 11 0.16 165.6 10.2 10.8
UL2464 24AWG*27C 11 0.16 169.7 10.2 10.8
UL2464 24AWG*28C 11 0.16 177.2 10.5 11.1
UL2464 24AWG*29C 11 0.16 181.3 10.5 11.1
UL2464 24AWG*30C 11 0.16 185.4 10.5 11.1
UL2464 24AWG*31C 11 0.16 193.4 10.9 11.5
UL2464 24AWG*32C 11 0.16 197.5 10.9 11.5
UL2464 24AWG*33C 11 0.16 201.6 10.9 11.5
UL2464 24AWG*34C 11 0.16 209.8 11.4 12
UL2464 24AWG*35C 11 0.16 213.9 11.4 12
UL2464 24AWG*36C 11 0.16 218 11.4 12
UL2464 24AWG*37C 11 0.16 222.1 11.4 12

UL2464 22AWG*2C 17 0.16 32.2 4.4 4.8
UL2464 22AWG*3C 17 0.16 38.1 4.7 5.1
UL2464 22AWG*4C 17 0.16 45.8 5.1 5.5
UL2464 22AWG*5C 17 0.16 54 5.6 6
UL2464 22AWG*6C 17 0.16 62.5 6 6.4
UL2464 22AWG*7C 17 0.16 68 6 6.4
UL2464 22AWG*8C 17 0.16 76.7 6.5 6.9
UL2464 22AWG*9C 17 0.16 87.2 7.2 7.6
UL2464 22AWG*10C 17 0.16 97.7 7.6 8
UL2464 22AWG*11C 17 0.16 105.8 7.9 8.3
UL2464 22AWG*12C 17 0.16 109.9 7.9 8.3
UL2464 22AWG*13C 17 0.16 114.1 8.3 8.7
UL2464 22AWG*14C 17 0.16 119.5 8.3 8.7
UL2464 22AWG*15C 17 0.16 128.6 8.8 9.2
UL2464 22AWG*16C 17 0.16 134 8.8 9.2
UL2464 22AWG*17C 17 0.16 143.4 9.2 9.6
UL2464 22AWG*18C 17 0.16 148.8 9.2 9.6
UL2464 22AWG*19C 17 0.16 154.3 9.2 9.6
UL2464 22AWG*20C 17 0.16 161.8 9.5 9.9
UL2464 22AWG*21C 17 0.16 169.2 9.7 10.1
UL2464 22AWG*22C 17 0.16 180.3 10.4 11.0
UL2464 22AWG*23C 17 0.16 190.2 10.8 11.4
UL2464 22AWG*24C 17 0.16 195.6 10.8 11.4
UL2464 22AWG*25C 17 0.16 203.3 11.1 11.7
UL2464 22AWG*26C 17 0.16 208.8 11.1 11.7
UL2464 22AWG*27C 17 0.16 214.2 11.1 11.7
UL2464 22AWG*28C 17 0.16 223.6 11.5 12.1
UL2464 22AWG*29C 17 0.16 229.1 11.5 12.1
UL2464 22AWG*30C 17 0.16 234.5 11.5 12.1
UL2464 22AWG*31C 17 0.16 244.5 12 12.6
UL2464 22AWG*32C 17 0.16 249.9 12 12.6
UL2464 22AWG*33C 17 0.16 255.3 12 12.6
UL2464 22AWG*34C 17 0.16 265.6 12.4 13.0
UL2464 22AWG*35C 17 0.16 271.1 12.4 13.0
UL2464 22AWG*36C 17 0.16 276.5 12.4 13.0
UL2464 22AWG*37C 17 0.16 281.9 12.4 13.0

UL2464 20AWG*2C 26 0.16 40.9 4.9 5.3
UL2464 20AWG*3C 26 0.16 48.9 5.2 5.6
UL2464 20AWG*4C 26 0.16 59.3 5.7 6.1
UL2464 20AWG*5C 26 0.16 70.4 6.2 6.6
UL2464 20AWG*6C 26 0.16 81.9 6.8 7.2
UL2464 20AWG*7C 26 0.16 89.5 6.8 7.2
UL2464 20AWG*8C 26 0.16 101.2 7.4 7.8
UL2464 20AWG*9C 26 0.16 115.3 8.1 8.5
UL2464 20AWG*10C 26 0.16 129.4 8.7 9.1
UL2464 20AWG*11C 26 0.16 140.5 8.9 9.3
UL2464 20AWG*12C 26 0.16 146.2 8.9 9.3
UL2464 20AWG*13C 26 0.16 151.6 9.4 9.8
UL2464 20AWG*14C 26 0.16 159.2 9.4 9.8
UL2464 20AWG*15C 26 0.16 171.4 10 10.4
UL2464 20AWG*16C 26 0.16 179 10 10.4
UL2464 20AWG*17C 26 0.16 191.6 10.5 11.1
UL2464 20AWG*18C 26 0.16 199.2 10.5 11.1
UL2464 20AWG*19C 26 0.16 206.9 10.5 11.1
UL2464 20AWG*20C 26 0.16 217.1 10.8 11.4
UL2464 20AWG*21C 26 0.16 227.3 11.1 11.7
UL2464 20AWG*22C 26 0.16 242.1 11.8 12.4
UL2464 20AWG*23C 26 0.16 255.3 12.4 13
UL2464 20AWG*24C 26 0.16 262.9 12.4 13
UL2464 20AWG*25C 26 0.16 273.5 12.7 13.3
UL2464 20AWG*26C 26 0.16 281.1 12.7 13.3
UL2464 20AWG*27C 26 0.16 288.7 12.7 13.3
UL2464 20AWG*28C 26 0.16 301.4 13.1 13.7
UL2464 20AWG*29C 26 0.16 309 13.1 13.7
UL2464 20AWG*30C 26 0.16 316.6 13.1 13.7
UL2464 20AWG*31C 26 0.16 330 13.7 14.3
UL2464 20AWG*32C 26 0.16 337.6 13.7 14.3
UL2464 20AWG*33C 26 0.16 345.3 13.7 14.3
UL2464 20AWG*34C 26 0.16 359.1 14.2 14.8
UL2464 20AWG*35C 26 0.16 366.7 14.2 14.8
UL2464 20AWG*36C 26 0.16 374.3 14.2 14.8
UL2464 20AWG*37C 26 0.16 381.9 14.2 14.8

UL2464 18AWG*2C 41 0.16 57.9 5.9 6.3
UL2464 18AWG*3C 41 0.16 69.9 6.2 6.6
UL2464 18AWG*4C 41 0.16 85.3 6.8 7.2
UL2464 18AWG*5C 41 0.16 94.2 7.4 7.8
UL2464 18AWG*6C 41 0.16 109.6 8 8.4
UL2464 18AWG*7C 41 0.16 119.6 8 8.4
UL2464 18AWG*8C 41 0.16 135.3 8.7 9.1
UL2464 18AWG*9C 41 0.16 154.3 9.6 10.2
UL2464 18AWG*10C 41 0.16 173.4 10.2 10.8
UL2464 18AWG*11C 41 0.16 188.2 10.6 11.2
UL2464 18AWG*12C 41 0.16 195.6 10.6 11.2
UL2464 18AWG*13C 41 0.16 202 11.2 11.8
UL2464 18AWG*14C 41 0.16 212 11.2 11.8
UL2464 18AWG*15C 41 0.16 228.3 11.8 12.4
UL2464 18AWG*16C 41 0.16 238.4 11.8 12.4
UL2464 18AWG*17C 41 0.16 255.3 12.5 13.1
UL2464 18AWG*18C 41 0.16 265.3 12.5 13.1
UL2464 18AWG*19C 41 0.16 275.3 12.5 13.1
UL2464 18AWG*20C 41 0.16 289 12.8 13.4
UL2464 18AWG*21C 41 0.16 302.5 13.1 13.7
UL2464 18AWG*22C 41 0.16 322.5 14 14.6
UL2464 18AWG*23C 41 0.16 340.3 14.7 15.3
UL2464 18AWG*24C 41 0.16 350.3 14.7 15.3
UL2464 18AWG*25C 41 0.16 364.5 15 16.2
UL2464 18AWG*26C 41 0.16 374.5 15 16.2
UL2464 18AWG*27C 41 0.16 384.5 15 16.2
UL2464 18AWG*28C 41 0.16 401.6 15.6 16.8
UL2464 18AWG*29C 41 0.16 411.6 15.6 16.8
UL2464 18AWG*30C 41 0.16 421.6 15.6 16.8
UL2464 18AWG*31C 41 0.16 439.7 16.2 17.4
UL2464 18AWG*32C 41 0.16 449.7 16.2 17.4
UL2464 18AWG*33C 41 0.16 459.7 16.2 17.4
UL2464 18AWG*34C 41 0.16 478.4 16.9 18.1
UL2464 18AWG*35C 41 0.16 488.4 16.9 18.1
UL2464 18AWG*36C 41 0.16 498.4 16.9 18.1
UL2464 18AWG*37C 41 0.16 508.4 16.9 18.1

UL2464 16AWG*2C 65 0.16 81.4 6.9 7.3
UL2464 16AWG*3C 65 0.16 99.1 7.3 7.7
UL2464 16AWG*4C 65 0.16 121.7 8 8.4
UL2464 16AWG*5C 65 0.16 145.6 8.8 9.2
UL2464 16AWG*6C 65 0.16 170.6 9.6 10
UL2464 16AWG*7C 65 0.16 188 9.6 10
UL2464 16AWG*8C 65 0.16 213.2 10.4 11.0
UL2464 16AWG*9C 65 0.16 243.4 11.5 12.1
UL2464 16AWG*10C 65 0.16 273.9 12.3 12.9
UL2464 16AWG*11C 65 0.16 298.3 12.8 13.4
UL2464 16AWG*12C 65 0.16 311.6 12.8 13.4
UL2464 16AWG*13C 65 0.16 322.2 13.5 14.1
UL2464 16AWG*14C 65 0.16 339.6 13.5 14.1
UL2464 16AWG*15C 65 0.16 365.9 14.2 14.8
UL2464 16AWG*16C 65 0.16 383.3 14.2 14.8
UL2464 16AWG*17C 65 0.16 410.5 15.1 16.3
UL2464 16AWG*18C 65 0.16 427.9 15.1 16.3
UL2464 16AWG*19C 65 0.16 445.3 15.1 16.3
UL2464 16AWG*20C 65 0.16 467.8 15.5 16.7
UL2464 16AWG*21C 65 0.16 490.2 15.9 17.1
UL2464 16AWG*22C 65 0.16 521.8 17 18.2
UL2464 16AWG*23C 65 0.16 550.3 17.8 19.0
UL2464 16AWG*24C 65 0.16 567.7 17.8 19.0
UL2464 16AWG*25C 65 0.16 591 18.2 19.4
UL2464 16AWG*26C 65 0.16 608.4 18.2 19.4
UL2464 16AWG*27C 65 0.16 625.8 18.2 19.4
UL2464 16AWG*28C 65 0.16 653.3 18.9 20.1
UL2464 16AWG*29C 65 0.16 670.7 18.9 20.1
UL2464 16AWG*30C 65 0.16 688.1 18.9 20.1
UL2464 16AWG*31C 65 0.16 717 19.7 20.9
UL2464 16AWG*32C 65 0.16 734.4 19.7 20.9
UL2464 16AWG*33C 65 0.16 751.8 19.7 20.9
UL2464 16AWG*34C 65 0.16 781.6 20.5 22.2
UL2464 16AWG*35C 65 0.16 799 20.5 21.7
UL2464 16AWG*36C 65 0.16 816.4 20.5 21.7
UL2464 16AWG*37C 65 0.16 833.8 20.5 21.7

UL2464 14AWG*2C 43 0.25 116.6 8.2 8.6
UL2464 14AWG*3C 43 0.25 143.8 8.7 9.1
UL2464 14AWG*4C 43 0.25 178.1 9.6 10
UL2464 14AWG*5C 43 0.25 214.6 10.6 11.2
UL2464 14AWG*6C 43 0.25 252.6 11.7 12.3
UL2464 14AWG*7C 43 0.25 279.9 11.7 12.3
UL2464 14AWG*8C 43 0.25 318.4 12.7 13.3
UL2464 14AWG*9C 43 0.25 364.4 14.1 14.7
UL2464 14AWG*10C 43 0.25 411.5 15.2 16.4
UL2464 14AWG*11C 43 0.25 449.4 15.7 16.9
UL2464 14AWG*12C 43 0.25 470.1 15.7 16.9
UL2464 14AWG*13C 43 0.25 484 16.6 17.8
UL2464 14AWG*14C 43 0.25 511.3 16.6 17.8
UL2464 14AWG*15C 43 0.25 551.6 17.6 18.8
UL2464 14AWG*16C 43 0.25 578.9 17.6 18.8
UL2464 14AWG*17C 43 0.25 620.5 18.6 19.8
UL2464 14AWG*18C 43 0.25 647.8 18.6 19.8
UL2464 14AWG*19C 43 0.25 675.2 18.6 19.8
UL2464 14AWG*20C 43 0.25 710.1 19.2 20.4
UL2464 14AWG*21C 43 0.25 744.7 19.7 20.9
UL2464 14AWG*22C 43 0.25 793 21.1 22.3
UL2464 14AWG*23C 43 0.25 836.7 22.1 23.3
UL2464 14AWG*24C 43 0.25 864 22.1 23.3
UL2464 14AWG*25C 43 0.25 900.1 22.6 23.8
UL2464 14AWG*26C 43 0.25 927.4 22.6 23.8
UL2464 14AWG*27C 43 0.25 954.7 22.6 23.8
UL2464 14AWG*28C 43 0.25 997.1 23.6 24.8
UL2464 14AWG*29C 43 0.25 1024.4 23.6 24.8
UL2464 14AWG*30C 43 0.25 1051.7 23.6 24.8
UL2464 14AWG*31C 43 0.25 1096.2 24.5 25.7
UL2464 14AWG*32C 43 0.25 1123.5 24.5 25.7
UL2464 14AWG*33C 43 0.25 1150.8 24.5 25.7
UL2464 14AWG*34C 43 0.25 1196.7 25.6 26.8
UL2464 14AWG*35C 43 0.25 1224.1 25.6 26.8
UL2464 14AWG*36C 43 0.25 1251.4 25.6 26.8
UL2464 14AWG*37C 43 0.25 1278.7 25.6 26.8



Contact Details
ECHU Special Wire & Cable (Kunshan) Co., Ltd.

Contact Person: Ms. Emma Zou

Tel: 86-150-21712369

Fax: 86-150-21712369

Send your inquiry directly to us (0 / 3000)
