Solar PV Cable TUV Cable 70.0mm2 with Red Jacket with TUV certificate

Name: Solar PV Cable TUV Cable 70.0mm2 with Red Jacket with TUV certificate
Brand: ECHU Special Wire & Cable (Kunshan) Co., Ltd.
SKU: PV1-F
Price: 0.10 USD
Availability: InStock

Brand Name:	ECHU
Model Number:	PV1-F
MOQ:	300Meter
Price:	USD0.102-USD0.836/M
Payment Terms:	T/T，Western Union, L/C
Supply Ability:	1000KM/Week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

TUV Certificate

Insulation:

XLPE

Jacket:

XLPE

Currect:

AC Cable

Voltage:

Low Or Middle Voltage

Feature:

Super Heat-proof, Flame Retardant, Halogen-free, Weathering Resistance

Conductor:

Stranded Tinned Copper Wire

Model:

PV1-F

Port:

Shanghai

HS Code:

854449

Packaging Details:

plywood reel or plywood box

Product Description

PVI-F (Solar Photovoltaic Cable)

Cable Structure:

Conductor: Stranded Tinned Rated Copper acc. to IEC60228+EN60228, VDE0295, CLASS 5

Inner jacket: XLPE UL4703

Jacket color: black/black, black/blue, red/red, blue/black ,black/red, red/black, blue/blue, others are optional

Out jacket: XLPE UL4703

Jacket color: black/black, black/blue, red/red, blue/black, black/red, red/black, blue/blue, others are optional

Properties:

Feature: super heat-proof, flame retardant, Halogen-free, Weathering resistance

Certificates: acc. to ROHS, TUV

Technical Data

Rated voltage: 600/1000V

Test voltage: 6500V

Minimumbending radius:

dia </=12mm 3XD

dia >/=12mm 4XD

Working temperature: Environmental Temp.: +90degree Cable highest Temp: +120degree Laying: -30 to +120 degree Fixed laying: -45 to +120 degree Short circuit: +250degree

Halogen free: No Hydrochloric acid acc. toEN50627-2-1, No fluorin acc. to EN60684-2

Flame retardant: flame retardant, self-extinguishing acc. to IEC60332-1-2 and EN60332-1-2

Typical Application:

Cable's insulation material improved the flame retardant feature and temperature usage scope, especially suitable to use as connection cable of solar appartus system, it can be used in different weather condition, outdoor environment,, also wer or dry indoor environment.


Cable Structure:		Technical Data
Conductor: Stranded Tinned Rated Copper acc. to IEC60228+EN60228, VDE0295, CLASS 5		Rated voltage: 600/1000V
		Test voltage: 6500V
Inner jacket: XLPE UL4703		Minimum bending radius: dia </=12mm 3XD dia >/=12mm 4XD
Jacket color: black/black, black/blue,red/red,blue/black,black/red,red/black,blue/blue, others are optional		Working temperature: Environmental Temp.: +90degree Cable highest Temp: +120degree Laying: -30 to +120 degree Fixed laying: -45 to +120 degree Short circuit: +250degree
Out jacket: XLPE UL4703
Jacket color: black/black, black/blue,red/red,blue/black,black/red,red/black,blue/blue, others are optional		Halogen free: No Hydrochloric acid acc. toEN50627-2-1 No fluorin acc. to EN60684-2 Flame retardant: flame retardant, self-extinguishing acc. to IEC60332-1-2 and EN60332-1-2
Properties:		Typical application:
Feature: super heat-proof, flame retardant		Cable's insulation material improved the flame retardant feature and temperature usage scope, especially suitable to use as connection cable of solar appartus system, it can be used in different weather condition, outdoor environment,, also wer or dry indoor environment.
Halogen-free
Weathering resistance
Certificates: acc. to ROHS, TUV
Part-No.	Section sqmm	Extermal Diameter mm	Weight kg/km
PVI-F	1.5	5.3	39
PVI-F	2.5	5.7	50
PVI-F	4	6.4	67
PVI-F	6	7.1	95
PVI-F	10	9.5	162
PVI-F	16	10.9	234
PVI-F	25	13.2	353
PVI-F	35	14.7	463
