Product Details:
Payment & Shipping Terms:
|
Insulation: | XLPE | Jacket: | XLPE |
---|---|---|---|
Currect: | AC Cable | Voltage: | Low Or Middle Voltage |
Feature: | Super Heat-proof, Flame Retardant, Halogen-free, Weathering Resistance | Conductor: | Stranded Tinned Copper Wire, |
Model: | PV1-F | Port: | Shanghai |
HS Code: | 854449 |
PV1-F 1*35.0MM2 Solar PV cable
Features:
1. Conductor: Copper acc. IEC 60228+EN60228, VDE0295 CLASS5, Tinned, Fine stranded copper conductor.
2. Temperature range for application is from -40C to 90C.
Max. Temperature at conductor can be 120C.
3. The permitted short circuit temperature referring to a period of 5s is 200C.
4. The solar PV cable is resistant to UV, ozone and hydrolysis.
5. It is also known for its high mechanical robustness and great resistance to water, oil and chemicals.
6. This solar PV cable is TUV approved, so customers can feel secure in using it.
Main Technical Specification of PV1-F 1*35.0 MM2 Solar PV cable
Specification Type PV1-F 1*35.0 MM2
Rated Voltage AC 0.6/1KV; DC 1.8KV
Test Voltage 6500V
Standard IEC 60228+EN60228, VDE0295 CLASS5
Nominal Cross-sectional Area 35.0 mm2
Flame Resistance IEC60332-1-2+EN60332-1-2
Inner Sheath XLPO sheath UL4703
Sheath XLPO sheath UL4703
Cable Approx. OD 14.7 MM
Cert. RoHS + TUV
Specification Type | PV1-F 1*35.0 MM2 |
Rated Voltage | AC 0.6/1KV; DC 1.8KV |
Test Voltage | 6500V |
Standard | IEC 60228+EN60228, VDE0295 CLASS5 |
Nominal Cross-sectional Area | 35.0 mm2 |
Flame Resistance | IEC60332-1-2+EN60332-1-2 |
Inner Sheath | XLPO sheath UL4703 |
Sheath | XLPO sheath UL4703 |
Cable Approx. OD | 14.7 MM |
Cert. | RoHs + TUV |
