ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color

Certification
Good quality Solar PV Cable for sales
Good quality Solar PV Cable for sales
I'm Online Chat Now

ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color

China ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier
ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color supplier

Large Image :  ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color

Product Details:

Place of Origin: China
Brand Name: ECHU
Certification: UL
Model Number: UL1284

Payment & Shipping Terms:

Minimum Order Quantity: 100meter
Price: USD1.2 to USD9.3
Packaging Details: in roll or splint reel
Payment Terms: Western Union,, T/T, L/C
Supply Ability: 10000km per week
Contact Now
Detailed Product Description

Product Description:

UL CERT.:E312831

UL1284: 1AWG, 2AWG, 3AWG,4AWG,5AWG,6AWG,7AWG,8AWG, 1/0AWG,2/0AWG, 3/0 AWG, 4/0AWG, 250Kcmil, 300kcmil,350kcmil, 400kcmil,450kcmil,500kcmil,500kcmil

Construction
Conductor :bare copper or tinned copper conductor Insulation: PVC
Standards
International: UL758 , UL1581
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature:105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
ROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black ColorROHS PVC UL1284 MTW 600V, 105℃ Bare Copper or Tinned Copper, 3AWG to 750MCM with Black Color

TYPE
Spec. AWG
Bare Copper

Tinned Copper

Insulation Thickness mm
Weight KG/KM


Conductor No.
Conductor Dia.
Conductor No.
Conductor Dia.


UL1284
8
118
0.3
118
0.30
2.03
138.4
UL1284
7
147
0.3
147
0.30
2.03
161.8
UL1284
6
189
0.3
189
0.30
2.03
194.9
UL1284
5
238
0.3
238
0.30
2.03
232.8
UL1284
4
299
0.3
299
0.30
2.03
279.0
UL1284
3
378
0.3
378
0.30
2.03
337.9
UL1284
2
475
0.3
475
0.30
2.03
409.1
UL1284
1
600
0.3
600
0.30
2.03
499.6
UL1284
1/0
251
0.52
272
0.50
2.03
609.7
UL1284
2/0
317
0.52
343
0.50
2.03
749.9
UL1284
3/0
400
0.52
433
0.50
2.03
924.3
UL1284
4/0
505
0.52
546
0.50
2.03
1142.9
UL1284
250
598
0.52
647
0.50
2.41
1372.4
UL1284
300
716
0.52
774
0.50
2.41
1617.7
UL1284
350
833
0.52
901
0.50
2.41
1859.5
UL1284
400
955
0.52
1033
0.50
2.41
2110.4
UL1284
450
1073
0.52
1161
0.50
2.41
2352.2
UL1284
500
1191
0.52
1288
0.50
2.41
2593.1
UL1284
550
1313
0.52
1420
0.50
2.79
2894.1
